Lithium Battery operate: improved discharge and charge efficiency, longer life span and the ability to deep cycle while maintaining power Compact Design makes it more flexible and easier to operate. Strong Traction with 1500kg Push or Pull capacity on 3% Slope. Tractive Drive wheels with a Pneumatic Tyre diameter of 250 mm. Easy to Charge, with the internal charger, the charging process can be realized where there is a 10amp socket. Comfortable in operation: the Tiller height is adjustable. Specifications Electric-Engine:Others: Characteristics: Part Number XL-H1500-RM Drive unit Battery Electric Operator type Pedestrian Rated capacity [Q] 1500 kg Rated drawbar Pull [F] 200 Wheelbase [Y] 315 mm Weights: Service weight (include battery) 98 kg Axle loading with load,driving side/loading side 98/0 kg Axle loading without load,driving side/loading side 78/20 kg Type; Chassis: Tyre type driving wheels/loading wheels Rubber Tyre size, driving wheels (diameter x width) 2x Ф250×85 Tyre size, loading wheels (diameter x width) 2x Ф75×32 Wheels, number driving/loading (x=drive wheels) 2x/2 Track width, front driving side [b10] 428 mm Track width, rear driving side [b11] 217 mm Dimensions: Standing height n/a Height drawbar in driving position, min./max. 835~930~1010 Tow coupling height scope n/a Overall Length 1255~1315~1345 Overall Width 520 mm Ground clearance, center of wheelbase n/a Performance: Travel speed, with/ without load 4.5/5 Km/h Drawbar pull, laden/unladen 200 N Max. drawbar pull, laden/unladen 650 N Gradeability, laden/unladen 3/16 % service brake mechanical Drive motor rating 60 min 0.4 kW The max allowed size battery 196/165/175 mm Battery Volatage/Nominal Capacity K20 24/50 V/Ah Type of driving control DC Steering Type Mechanical Sound pressure level at the driver’s ear 74 dB (A) 1. The parameters in the table are of the standard model.2. The parameters are subject to change without notice.
